Ratchet Lever Hoist

7 models · 0.25 to 9 t

Ratchet Lever Hoist — German design and technology. Grade 80 alloy steel chain. 7 models are listed, each with its item code.

SizeNot selected Choose a size

Direct Enquiry

Interested in this product?

Get pricing, availability and product details from Steel Tools India.

Sizes & variants

Every size below is as listed in the catalogue. Select one and it's included in your enquiry automatically.

No size selectedChoose one below and it's added to your WhatsApp / email enquiry.

7 sizes listed

Item Code	Capacity (Tons)	Standard Lift (Mtr)	Effort Required Lift (N)	Load Chain Diameter (mm)	Load Chain Fall	Dimension A (mm)	Dimension B (mm)	Dimension C (mm)	Dimension D (mm)	Dimension H (mm)	Dimension L (mm)	Dimension K (mm)	Net Weight (kg)	Extra Weight /Mtr of Extra
RLSL0215	0.25	1.5	160	5	1	119	79	90.5	31	237	168	24	2.7	0.4
RLSL0515	0.5	1.5	140	5	1	135	85	110	35	290	180	21	2.81	0.6
RLSL0715	0.8	1.5	140	6	1	150	90	140	39	365	245	28.5	5.96	0.78
RLSL1515	1.6	1.5	220	8	1	170	107	165	50.2	450	320	38.4	9.14	1.38
RLSL3015	3.2	1.5	320	10	1	200	120	215	59.5	545	375	42.1	15.92	2.15
RLSL6015	6.3	1.5	340	10	2	205	120	215	66.5	700	380	48	22.58	4.3
RLSL9015	9	1.5	340	10	3	210	125	215	93.5	800	400	56	34.3	6.5

Technical data

Ratchet Lever Hoist
