Hoists, Pulley Blocks & TrolleysTrolleys
Gear Trolley
6 models · 1 to 20 t
Gear Trolley — anti corrosive powder coated finish. Use of high quality bearings. 6 models are listed, each with its item code.
Direct Enquiry
Interested in this product?
Get pricing, availability and product details from Steel Tools India.
- Several items or a drawing to send? Use the quote form
- Prefer to talk? Call +91 98302 58198
Sizes & variants
Choose a size
Every size below is as listed in the catalogue. Select one and it's included in your enquiry automatically.
No size selectedChoose one below and it's added to your WhatsApp / email enquiry.
6 sizes listed
| Select | Item Code | Capacity | I-Beam Width (mm) | Dimension A | Dimension B | Dimension C | Dimension H | Dimension F | Dimension M | Net Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| GTSL0103 | 1 t | 90-120 | 220 | 220 | 205 | 120 | 8 | 90 | 10.3 | |
| GTSL0203 | 2 t | 100-125 | 230 | 235 | 220 | 125 | 10 | 100 | 14.5 | |
| GTSL0303 | 3 t | 110-160 | 260 | 275 | 260 | 160 | 10 | 110 | 21.3 | |
| GTSL0503 | 5 t | 140-160 | 320 | 360 | 345 | 210 | 14 | 140 | 38.8 | |
| GTSL1003 | 10 t | 140-210 | 430 | 410 | 425 | 270 | 23 | 175 | 63.5 | |
| GTSL2003 | 20 t | 122-210 | 475 | 798 | 575 | 300 | — | — | — |
Technical data
Specifications
- Feature
- Anti corrosive powder coated finish
- Feature
- Use of high quality bearings
- Feature
- Adjustable to various rail widths
