Solid Carbide ToolsSquare Endmills
Square Endmill HRC55 · 4 Flute
Ø1–20 mm · TiSiN coated
Four-flute solid carbide square endmill in the HRC55 range with TiSiN copper coating, listed from Ø1 to Ø20 mm with lengths up to 200 mm.
Direct Enquiry
Interested in this product?
Get pricing, availability and product details from Steel Tools India.
- Several items or a drawing to send? Use the quote form
- Prefer to talk? Call +91 98302 58198
Sizes & variants
Choose a size
Every size below is as listed in the catalogue. Select one and it's included in your enquiry automatically.
No size selectedChoose one below and it's added to your WhatsApp / email enquiry.
57 sizes listed
| Select | Cut Ø (mm) | Flute L (mm) | Shank Ø (mm) | Total L (mm) |
|---|---|---|---|---|
| 1 | 3 | 4 | 50 | |
| 1.5 | 5 | 4 | 50 | |
| 2 | 6 | 4 | 50 | |
| 2.5 | 8 | 4 | 50 | |
| 3 | 9 | 3 | 50 | |
| 3 | 9 | 4 | 50 | |
| 3 | 9 | 6 | 50 | |
| 3 | 12 | 3 | 75 | |
| 3 | 15 | 3 | 100 | |
| 3 | 40 | 3 | 100 | |
| 3.5 | 11 | 4 | 50 | |
| 4 | 12 | 4 | 50 | |
| 4 | 12 | 6 | 50 | |
| 4 | 16 | 4 | 75 | |
| 4 | 20 | 4 | 100 | |
| 4.5 | 12 | 6 | 50 | |
| 5 | 13 | 5 | 50 | |
| 5 | 13 | 6 | 50 | |
| 5 | 18 | 5 | 75 | |
| 5 | 30 | 5 | 100 |
Technical data
Specifications
- Range
- HRC55
- Flutes
- 4
- Coating
- TiSiN (copper)
- Diameter range
- 1–20 mm
- ISO material range
- P (steel), K (cast iron)
- Machining operations
- Slotting, side milling, ramping, helical, plunging
