Solid Carbide ToolsSolid Carbide Drills
Solid Carbide Drill HRC55 · 2 Flute
Ø0.5–20 mm · TiSiN coated
Two-flute solid carbide drill in the HRC55 range with TiSiN copper coating. Listed from Ø0.5 to Ø20 mm; ranges step in 0.1 mm, so a range such as 5.2–6.1 covers every size between.
Direct Enquiry
Interested in this product?
Get pricing, availability and product details from Steel Tools India.
- Several items or a drawing to send? Use the quote form
- Prefer to talk? Call +91 98302 58198
Sizes & variants
Choose a size
Every size below is as listed in the catalogue. Select one and it's included in your enquiry automatically.
No size selectedChoose one below and it's added to your WhatsApp / email enquiry.
31 sizes listed
| Select | Cut Ø (mm) | Flute L (mm) | Total L (mm) |
|---|---|---|---|
| 0.5–0.9 | 12 | 34 | |
| 1.0–2.0 | 20 | 40 | |
| 2.1–3.0 | 20 | 40 | |
| 2.1–2.5 | 30 | 57 | |
| 2.6–3.0 | 35 | 65 | |
| 3.1–4.1 | 25 | 50 | |
| 3.1–4.1 | 35 | 65 | |
| 3.3 | 40 | 75 | |
| 3.3 | 50 | 100 | |
| 4.2–5.1 | 25 | 50 | |
| 4.2–5.1 | 40 | 75 | |
| 4.2–5.1 | 50 | 100 | |
| 5.2–6.1 | 40 | 75 | |
| 5.2–6.1 | 60 | 100 | |
| 5.8 | 25 | 50 | |
| 6.2–7.1 | 60 | 100 | |
| 7.2–8.1 | 60 | 100 | |
| 8.2–9.1 | 60 | 100 | |
| 8.5 | 50 | 80 | |
| 9.2–10.1 | 60 | 100 |
Technical data
Specifications
- Range
- HRC55
- Flutes
- 2
- Coating
- TiSiN (copper)
- Diameter range
- 0.5–20.0 mm
- Size steps
- Ranges step in 0.1 mm
- ISO material range
- P (steel), K (cast iron)
- Machining operations
- Drilling
Solid Carbide Drill HRC55 · 2 Flute
