Lifting Chain, Hooks & RiggingG80 Hooks
G80 Eye Self Locking Hook
8 models · 1.12 to 21.2 t
G80 Eye Self Locking Hook — forged super alloy steel. 100% tested at 2.5 times working load limit. 8 models are listed, each with its item code. Standard: EN 818-8.
Direct Enquiry
Interested in this product?
Get pricing, availability and product details from Steel Tools India.
- Several items or a drawing to send? Use the quote form
- Prefer to talk? Call +91 98302 58198
Sizes & variants
Choose a size
Every size below is as listed in the catalogue. Select one and it's included in your enquiry automatically.
No size selectedChoose one below and it's added to your WhatsApp / email enquiry.
8 sizes listed
| Select | Item Code | Ton | Dimension E | Dimension O | Dimension D | Dimension K | Dimension H | Dimension R | WEIGHT |
|---|---|---|---|---|---|---|---|---|---|
| SLHSL081 | 1.12 | 31.5 | 21.4 | 10.8 | 108.3 | 20.1 | 32.6 | 0.47 | |
| SLHSL082 | 2 | 43.1 | 24.4 | 12.5 | 136.3 | 28 | 41.4 | 0.87 | |
| SLHSL083 | 3.15 | 52.4 | 31.6 | 15.2 | 165.3 | 30.3 | 54.5 | 1.41 | |
| SLHSL085 | 5.3 | 67.5 | 39.5 | 20.3 | 210 | 38.6 | 65.5 | 3.14 | |
| SLHSL088 | 8 | 78.3 | 55.3 | 22.3 | 250 | 51.5 | 80.4 | 5.75 | |
| SLHSL812 | 12.5 | 77.5 | 62.1 | 28.1 | 275.2 | 54.7 | 96 | 8.2 | |
| SLHSL815 | 15 | 80 | 70 | 32 | 312 | 67 | 77 | 12.6 | |
| SLHSL822 | 21.2 | 109 | 80 | 34 | 362 | 75 | 97 | 21.9 |
Technical data
Specifications
- Standard
- EN 818-8
- Feature
- Forged super alloy steel
- Feature
- 100% tested at 2.5 times working load limit
- Feature
- 100% magnaflux crack detection
- Feature
- Ultimate break load tested
- Feature
- Fatigue tested at 1.5 times working load limit for 20000 cycles
- Feature
- Suitable for EN 818-8 Gr.80 chain
- Feature
- All shackles are drop forged
